PET Monafilament Braided Expandable Sleeving Cable Protection Black
Sleeving Automobile
Specifications:
Economical & easy to install light weight, and flexible
Easy to be Cut & abrasion resistant
Halogen free
Feature:
| Material: | PET | Melting Point: | 230°C+5 |
|---|
| Temperature Range: | -50°C ~+150°C | Fire Resistance Rating: | VW-1 |
|---|
| Certificate: | SGS, Reach And ROHS | Colors: | Black/white/clrear/blue/ pink/yellow/red/yellow |
|---|
Technical data:
1. Size: 3mm~76mm
2. Operating range: -103F to 257F (-75C to 125C) temperature range
3. Melt Point:446F (230C)
4. Expands up to 150%
5. Available up to 4" in diameter
6. Colors:black, grey, white, red, green, blue, yellow, purple,
pink, orange etc.
7.Certificate: SGS, UL, RoHS approved
8.Halogen free
Advantages:
1. Economical & easy to install light weight, and flexible
2.Resists gasoline, chemicals & cleaning solvents
3.High tensile strength
4. Easy to be Cut & abrasion resistant
Description and Application:
Our PET expandable sleeving is braided from 0.20MM or 0.25MM
polyethylene terepthalate (PET) monofilament yarn. The sleeving
easily expands up to 150% and gently constricts around irregular
shapes. It remains flexible over a wide temperature range and is
resistant to chemical degradation, UV radiation and abrasion.
Expandable braided sleeves is ideal for a limitless number of
electronic, automotive, marine and industrial wire management and
bundling applications. Examples include engine compartment dress
up, home theater wire management, customizing computer case wiring,
office wire management, automotive harnesses, scuba hose
protection, and many more. Threads of different colors and textures
could be woven into different patterns. Each of our products is
tailored to the client's business and needs.
Specification:
Part Number |
SIZE |
Material |
Expandable Range |
Temperature Range |
mm |
inch |
mm |
inch |
PET03 |
3MM |
1/8" |
Polyester(PET) |
2.4--6.4 |
3/32"--1/4" |
-103°F-- 257°F |
-75°C-- 125°C |
PET06 |
6MM |
1/4" |
Polyester(PET) |
3.2--11.1 |
1/8"--7/16" |
-103°F-- 257°F |
-75°C-- 125°C |
PET08 |
8MM |
5/16" |
Polyester(PET) |
6.4--12.7 |
1/4"--1/2" |
-103°F-- 257°F |
-75°C-- 125°C |
PET10 |
10MM |
3/8" |
Polyester(PET) |
4.8--15.9 |
3/16"--5/8" |
-103°F-- 257°F |
-75°C-- 125°C |
PET12 |
12MM |
1/2" |
Polyester(PET) |
6.4--19.1 |
1/4"--3/4" |
-103°F-- 257°F |
-75°C-- 125°C |
PET16 |
16MM |
5/8" |
Polyester(PET) |
9.5--25.4 |
3/8"--1" |
-103°F-- 257°F |
-75°C-- 125°C |
PET19 |
19MM |
3/4" |
Polyester(PET) |
12.7--31.8 |
1/2"--1-1/4" |
-103°F-- 257°F |
-75°C-- 125°C |
PET25 |
25MM |
1" |
Polyester(PET) |
15.9--38.1 |
5/8"--1-1/2" |
-103°F-- 257°F |
-75°C-- 125°C |
PET32 |
32MM |
1 -1/4" |
Polyester(PET) |
19.1--44.5 |
3/4"--1-3/4" |
-103°F-- 257°F |
-75°C-- 125°C |
PET38 |
38MM |
1 -1/2" |
Polyester(PET) |
25.4--63.5 |
1"--2-1/2" |
-103°F-- 257°F |
-75°C-- 125°C |
PET45 |
45MM |
1 -3/4" |
Polyester(PET) |
31.8--69.9 |
1-1/4"--2-3/4" |
-103°F-- 257°F |
-75°C-- 125°C |
PET51 |
51MM |
2" |
Polyester(PET) |
38.1--88.9 |
1-1/2"--3-1/2" |
-103°F-- 257°F |
-75°C-- 125°C |
PET64 |
64MM |
2 -1/2" |
Polyester(PET) |
44.5--114.3 |
1-3/4"--4-1/2" |
-103°F-- 257°F |
-75°C-- 125°C |
PET76 |
76MM |
3" |
Polyester(PET) |
63.5--120.7 |
2-1/2"--4-3/4" |
-103°F-- 257°F |
-75°C-- 125°C |
